Applicable scope: applicable to all kinds of materials, such as loose fiber, yarn, fabric block (knitting fabric, woven fabric), and can be used to

To make the dyeing level and repeatable test samples more accurate.

With accurate temperature control and stable repeatability, it can be accurately used for field test and duplicate sample. The new design concept of environmental protection and economy can realize high energy conservation

Dye test with zero emission and easy operation.

Technical features:

Specially designed heating tube with heat transfer oil realizes accurate temperature control effect;

The maximum power consumption is 2KW, and air cooling is used;

Temperature control range: room temperature to 145 ℃;

The bath ratio can be as low as 1:5, and the sample can be stained with 50g at most;

The average power consumption during insulation compensation is less than 100W;

L stainless steel test cup;

Temperature control computer system temperature control, LCD display;

Capable of editing and storing 100 programs, 100 steps for each program;

• Conventional sample preparation and independent sample cup insertion;

• Sample cups can be conveniently removed or inserted during the process;

• Consistency and reproducibility between sample cups;

• *When opening the door, the rotating frame will stop rotating to prevent safety hazards;

• When the actual temperature exceeds 140°C, an alarm will be triggered and the operation will stop.

3. Technical Parameters:

4. Standard Configuration:
